Brand Name : | fangda |
Model Number : | 0.2-0.7mm |
Certification : | no |
Payment Terms : | T/T, Western Union, MoneyGram |
Supply Ability : | 100 ton per month |
Delivery Time : | 7-15days |
Production process: It is made of high-quality low-carbon steel
wire rod. It is made of high-quality low-carbon steel. It is
processed through drawing process, pickling and rust removal, high
temperature annealing, hot galvanizing and cooling processes.
Galvanized wire characteristics: Galvanized iron wire has good
toughness and elasticity, the highest zinc amount can reach 300
g/m2. With galvanized layer thickness, strong corrosion resistance
and other characteristics.
Galvanized wire applications: Products are widely used in various
fields such as construction, handicrafts, preparation of wire mesh,
highway barriers, product packaging and daily civilian use.
nominal diameter | tensile strength | stress at 1% elongation | twist | elongation | standard |
mm | Mpa | Mpa | Times/360°C | Lo=250mm | As per GB,EN,IEC,JIS, ASTM standard,as well as customer's request |
1.24-2.25 | ≥1340 | ≥1170 | ≥18 | ≥3% | |
2.25-2.75 | ≥1310 | ≥1140 | ≥16 | ≥3% | |
2.75-3.00 | ≥1310 | ≥1140 | ≥16 | ≥3.5% | |
3.00-3.50 | ≥1290 | ≥1100 | ≥14 | ≥3.5% | |
3.50-4.25 | ≥1290 | ≥1100 | ≥12 | ≥4% | |
4.25-4.75 | ≥1290 | ≥1100 | ≥12 | ≥4% | |
4.75-5.50 | ≥1290 | ≥1100 | ≥12 | ≥4% |
![]() |
